R1Z-1209/P
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
RECOM POWER R1Z-1209/PIsolated Board Mount DC/DC Converter, Medical, Fixed, 1 Output, 11.4 V, 12.6 V, 1 W, 9 V
PDF
/
Inventory: 9477
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module, 6 Leads
Weight 1.6g
Technical
Operating Temperature -40°C~70°C
Packaging Tube
Series ECONOLINE R1Z (1W)
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
JESD-609 Code e1
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-XDMA-G6
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 60%
Voltage - Isolation 1kV
Voltage - Input (Max) 12.6V
Output Voltage 9V
Max Output Current 111mA
Voltage - Input (Min) 11.4V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 111mA
Output Power 1W
Max Output Voltage 9V
Total Power Output-Max 1W
Dimensions
Height 8.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
