R1DA-153.33.3
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 3.3V 1W
PDF
/
Buying Options
Total Price: USD $20.67
Unit Price: USD $20.672923
≥1 USD $20.672923
≥198 USD $8.248951
≥495 USD $7.973242
≥990 USD $7.838013
Inventory: 4789
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module, 7 Leads
Weight 1.2g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R1DA (1W)
Size / Dimension 0.60Lx0.42W x 0.28 H 15.2mmx10.7mmx7.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature IT ALSO HAS 3.3V OUTPUT
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
JESD-30 Code R-XDMA-G7
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 1kV
Voltage - Input (Max) 16.5V
Output Voltage 3.3V
Max Output Current 33mA
Voltage - Input (Min) 13.5V
Input Voltage-Nom 15V
Trim/Adjustable Output NO
Current - Output (Max) 33mA 33mA
Output Power 1W
Max Output Voltage 3.3V
Total Power Output-Max 1W
Dimensions
Height 7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
