R1D12-3.309/HP
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 3.3VIN +/-09VOUT
PDF
/
Inventory: 5609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SMD Module, 10 Leads
Weight 1.2g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R1D (1W)
Size / Dimension 0.60Lx0.42W x 0.28 H 15.2mmx10.7mmx7.0mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 255
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 5
JESD-30 Code R-XDMA-G10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 78%
Voltage - Isolation 3kV
Voltage - Input (Max) 3.6V
Output Voltage 9V
Max Output Current 56mA
Voltage - Input (Min) 3V
Input Voltage-Nom 3.3V
Trim/Adjustable Output NO
Current - Output (Max) 56mA 56mA
Output Power 1W
Max Output Voltage 9V
Voltage - Output 2 -9V
Total Power Output-Max 1W
Nominal Input Voltage 3.3V
Dimensions
Height 6.7mm
Width 10.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
