R1D12-1224
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 12VIN +/-24VOUT
PDF
/
Inventory: 8047
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Output Voltage 24V
Max Output Current 21mA
Voltage - Input (Min) 10.8V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 21mA 21mA
Output Current 21mA
Output Power 1W
Max Output Voltage 24V
Voltage - Output 2 -24V
Total Power Output-Max 1W
Nominal Input Voltage 12V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) 5
Number of Functions 1
Peak Reflow Temperature (Cel) 255
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.60Lx0.42W x 0.28 H 15.2mmx10.7mmx7.0mm
Series ECONOLINE R1D (1W)
Packaging Tube
Operating Temperature -40°C~100°C
Dimensions
Height 6.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 1.2g
Number of Pins 10
Package / Case 12-SMD Module, 10 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
