R1D10-1215
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 12VIN +/-15VOUT
PDF
/
Inventory: 8826
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module
Number of Pins 10
Weight 1.2g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R1D (1W)
Size / Dimension 0.60Lx0.42W x 0.28 H 15.2mmx10.7mmx7.0mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 255
Number of Functions 1
Depth 10.7mm
Time@Peak Reflow Temperature-Max (s) 5
Pin Count 10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 1kV
Voltage - Input (Max) 13.2V
Output Voltage 15V
Max Output Current 33mA
Voltage - Input (Min) 10.8V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 33mA 33mA
Output Current 33mA
Output Power 1W
Max Output Voltage 15V
Voltage - Output 2 -15V
Total Power Output-Max 1W
Nominal Input Voltage 12V
Isolation Isolated
Dimensions
Height 6.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
