R1D-2415/HP
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 24VIN +/-15VOUT
PDF
/
Buying Options
Total Price: USD $9.87
Unit Price: USD $9.8736
≥1 USD $9.8736
≥10 USD $9.7944
≥100 USD $9.72048
≥500 USD $9.570528
≥1000 USD $9.271504
≥3000 USD $8.4568
Inventory: 113
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module, 6 Leads
Number of Pins 6
Weight 1.2g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R1D (1W)
Size / Dimension 0.60Lx0.42W x 0.28 H 15.2mmx10.7mmx7.0mm
JESD-609 Code e1
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 255
Number of Functions 1
Depth 10.7mm
Time@Peak Reflow Temperature-Max (s) 5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 3kV
Voltage - Input (Max) 26.4V
Output Voltage 15V
Max Output Current 33mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 33mA 33mA
Output Current 33mA
Output Power 1W
Max Output Voltage 15V
Voltage - Output 2 -15V
Total Power Output-Max 1W
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 6.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
