R12P23.3D
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 12VIN +/-3.3VOUT
PDF
/
Buying Options
Total Price: USD $13.09
Unit Price: USD $13.092916
≥1 USD $13.092916
≥10 USD $12.351812
≥100 USD $11.652651
≥500 USD $10.993069
≥1000 USD $10.370819
Inventory: 1471
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Number of Pins 5
Weight 4.3g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RxxP2xx (2W)
Size / Dimension 0.77Lx0.39W x 0.49 H 19.7mmx9.8mmx12.5mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 70%
Voltage - Isolation 6.4kV
Voltage - Input (Max) 13.2V
Output Voltage 3.3V
Max Output Current 300mA
Voltage - Input (Min) 10.8V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 300mA 300mA
Output Current 300mA
Output Power 2W
Max Output Voltage 3.3V
Voltage - Output 2 -3.3V
Total Power Output-Max 2W
Nominal Input Voltage 12V
Isolation Isolated
Dimensions
Height 12.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
