R12P12S/P/X2
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 1W 12VIN 12VOUT CONT SHORT CIR PRTCT
PDF
/
Buying Options
Total Price: USD $18.94
Unit Price: USD $18.93715
≥1 USD $18.93715
≥10 USD $17.86524
≥100 USD $16.854
≥500 USD $15.9
≥1000 USD $15
≥3000 USD $14.15094
Inventory: 9664
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 9.8mm
Height 12.5mm
Technical
Nominal Input Voltage 12V
Total Power Output-Max 1W
Current - Output 1 84mA
Max Output Voltage 12V
Output Power 1W
Output Current 84mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 84mA
Output Voltage 12V
Voltage - Input (Max) 13.2V
Voltage - Isolation 6.4kV
Efficiency 75%
Number of Outputs 1
JESD-30 Code R-XSMA-P4
Pin Count 7/4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.39W x 0.49 H 19.5mmx9.8mmx12.5mm
Series ECONOLINE RxxPxx (1W)
Packaging Tube
Operating Temperature -40°C~90°C
Physical
Weight 4.3g
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
