R09P05S/P/X2
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 1W 09VIN 05VOUT CONT SHORT CIR PRTCT
PDF
/
Inventory: 8457
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 4 Leads
Weight 4.3g
Technical
Operating Temperature -40°C~90°C
Packaging Tube
Series ECONOLINE RxxPxx (1W)
Size / Dimension 0.77Lx0.39W x 0.49 H 19.5mmx9.8mmx12.5mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/4
JESD-30 Code R-XSMA-P4
Number of Outputs 1
Efficiency 75%
Voltage - Isolation 6.4kV
Voltage - Input (Max) 9.9V
Output Voltage 5V
Max Output Current 200mA
Voltage - Input (Min) 8.1V
Input Voltage-Nom 9V
Trim/Adjustable Output NO
Output Current 200mA
Output Power 1W
Max Output Voltage 5V
Current - Output 1 111mA
Total Power Output-Max 1W
Nominal Input Voltage 9V
Dimensions
Height 12.5mm
Width 9.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
