R0.5S-2405/H
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
0.5W DC/DC-Converter 'ECONOLINE' SMD 3kV unreg; V. In: 24; V. Out: 05; mA. Out: 100
PDF
/
Inventory: 8665
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD Module, 5 Leads
Weight 1g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R0.5S (0.5W)
Size / Dimension 0.50Lx0.42W x 0.28 H 12.8mmx10.7mmx7.0mm
JESD-609 Code e1
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 500mW
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 2.54mm
JESD-30 Code R-XDMA-G5
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 3kV
Voltage - Input (Max) 26.4V
Output Voltage 5V
Max Output Current 100mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 100mA
Output Power 500mW
Max Output Voltage 5V
Total Power Output-Max 0.5W
Dimensions
Height 7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
