R0.5D12-1215/HP
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
0.5W DC/DC-CONVERTER ECONOLINE
PDF
/
Inventory: 2066
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SMD Module, 10 Leads
Weight 1.3g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R0.5D (0.5W)
Size / Dimension 0.60Lx0.42W x 0.28 H 15.2mmx10.7mmx7.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 500mW
Terminal Position DUAL
Terminal Form GULL WING
JESD-30 Code R-PDSO-G10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 3kV
Voltage - Input (Max) 13.2V
Output Voltage 15V
Max Output Current 17mA
Voltage - Input (Min) 10.8V
Current - Output (Max) 17mA 17mA
Output Current 17mA
Output Power 500mW
Max Output Voltage 15V
Voltage - Output 2 -15V
Dimensions
Height 7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
