R0.25S-1209
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 0.25W 12V IN 9V OUT
PDF
/
Inventory: 3647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 7mm
Technical
Nominal Input Voltage 12V
Total Power Output-Max 0.25W
Current - Output 1 28mA
Max Output Voltage 9V
Output Power 250mW
Output Current 28mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 28mA
Output Voltage 9V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 60 ~ 70%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-G5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 250mW
Subcategory Other Analog ICs
Applications ITE (Commercial)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
JESD-609 Code e1
Size / Dimension 0.49Lx0.42W x 0.28 H 12.8mmx10.7mmx7.0mm
Series ECONOLINE R0.25S (0.25W)
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 1g
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
