R-723.3P
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2A 4.5-28VIN 3.3V
PDF
/
Buying Options
Total Price: USD $30.3
Unit Price: USD $30.29945
≥1 USD $30.29945
≥10 USD $28.58438
≥100 USD $26.9664
≥500 USD $25.44
≥1000 USD $24
≥3000 USD $22.64151
Inventory: 1205
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 12-SIP Module
Number of Pins 12
Weight 9g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series INNOLINE R-7xxx
Size / Dimension 1.27Lx0.36W x 0.59 H 32.2mmx9.1mmx15.0mm
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 11W
Max Power Dissipation 6.6W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 9.1mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 95%
Voltage - Input (Max) 28V
Output Voltage 5.5V
Max Output Current 2A
Voltage - Output 1 3.3V
Voltage - Input (Min) 4.5V
Trim/Adjustable Output YES
Output Current 2A
Output Power 6.6W
Control Features Enable, Active High
Max Output Voltage 5.5V
Nominal Input Voltage 24V
Isolation Non-Isolated
Isolation Voltage 1kV
Dimensions
Height 15mm
Length 32.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
