R-623.3D
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2A 9-32VIN 3.3V
PDF
/
Inventory: 1445
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 32.2mm
Height 15mm
Technical
Isolation Voltage 8kV
Isolation Non-Isolated
Nominal Input Voltage 24V
Max Output Voltage 6V
Control Features Enable, Active High
Output Current 2A
Trim/Adjustable Output YES
Voltage - Input (Min) 9V
Voltage - Output 1 3.3V
Max Output Current 2A
Output Voltage 1.8V
Voltage - Input (Max) 32V
Efficiency 86%
Number of Outputs 1
Depth 15mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6.6W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 1.27Lx0.59W x 0.36 H 32.2mmx15.0mmx9.1mm
Series INNOLINE R-6xxx
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 9g
Number of Pins 12
Package / Case 12-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
