UCH-3.3/30-D48NB-C
RoHS
/
Package 9-DIP Module, 1/2 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 99W
PDF
/
Inventory: 3833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 9-DIP Module, 1/2 Brick
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series UCH
Size / Dimension 2.40Lx2.30W x 0.40 H 61.0mmx58.4mmx10.2mm
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish GOLD OVER NICKEL
Applications ITE (Commercial)
Power Rating 99W
Max Power Dissipation 99W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Depth 61mm
Pin Count 9
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Efficiency 90%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 75V
Output Voltage 3.3V
Max Output Current 30A
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Current 30A
Output Power 99W
Current - Output 1 30A
Nominal Input Voltage 48V
Max Output Power 99W
Nominal Output Voltage 3.3V
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 36V
Dimensions
Height 10.16mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
