MPDTH05020WAH image
Favorite
MPDTH05020WAH image
Favorite
RoHS
/
Package 10-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 79.2W .8-3.6VOUT 22A
PDF
/
Inventory: 2827
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Length 37.97mm
Height 8.89mm

Technical

Isolation Non-Isolated
Total Power Output-Max 72.6W
Output Power 79.2W
Output Current 22A
Trim/Adjustable Output YES
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 0.8V~3.6V
Max Output Current 22A
Output Voltage 3.6V
Voltage - Input (Max) 5.5V
Efficiency 95%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 10
Reach Compliance Code unknown
Depth 22.1mm
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 79.2W
Power (Watts) 79W
Applications ITE (Commercial)
Terminal Finish TIN SILVER COPPER
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 1.50Lx0.87W x 0.35 H 38.1mmx22.1mmx9.0mm
Series MPD
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 10
Package / Case 10-DIP Module
Mounting Type Through Hole
Mount Through Hole
