LXDC55KAAA-205 image
Favorite
LXDC55KAAA-205 image
Favorite

LXDC55KAAA-205

Murata Electronics
RoHS
/
Package 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC/DC CONVERTER 3.6V 3A SMD
PDF
/
Buying Options
Total Price: USD $37.22
Unit Price: USD $37.221307
≥1 USD $37.221307
≥10 USD $35.11444
≥100 USD $33.126829
≥500 USD $31.251723
≥1000 USD $29.48276
Inventory: 1118
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 5.6896mm
Length 5.6896mm
Height 2.0066mm

Technical

Current - Output 1 3A
Max Input Voltage 5.5V
Min Input Voltage 2.7V
Control Features Enable, Active High
Current - Output (Max) 3A
Voltage - Input (Min) 2.7V
Operating Supply Voltage 5.5V
Voltage - Output 1 0.8V~3.6V
Max Output Current 3A
Output Voltage 3.6V
Voltage - Input (Max) 5.5V
Efficiency 93%
Number of Outputs 1
Max Power Dissipation 11W
Power (Watts) 11W
Applications ITE (Commercial)
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Non-Isolated PoL Module
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature OCP, OTP, UVLO
Size / Dimension 0.20Lx0.22W x 0.08 H 5.0mmx5.7mmx2.1mm
Packaging Digi-Reel?
Operating Temperature -40°C~85°C

Physical

Number of Pins 14
Package / Case 14-SMD Module
Mounting Type Surface Mount
