LXDC3EP12A-104
RoHS
/
Package 9-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
MURATA LXDC3EP12A-104 Non Isolated POL DC/DC Converter, Step Down, Fixed, 1 V, 3.3 V, 1 A
PDF
/
Inventory: 8761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.2mm
Height 1.3mm
Technical
Ambient Temperature Range High 85°C
Switching Frequency 4MHz
Min Input Voltage (DC) 2.5V
Max Input Voltage (DC) 5.5V
Nominal Output Voltage 3.3V
Min Output Voltage 1V
Current - Output 1 1A
Max Output Voltage 3.3V
Output Current 1A
Min Supply Voltage 2.5V
Max Supply Voltage 5.5V
Trim/Adjustable Output NO
Input Voltage-Nom 3.7V
Operating Supply Voltage 5.5V
Max Output Current 1A
Output Type Fixed
Output Voltage 1.2V
Efficiency 88%
Number of Outputs 1
Depth 3.5mm
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 1W
Power (Watts) 3W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, UVLO
Size / Dimension 0.14Lx0.13W x 0.05 H 3.5mmx3.2mmx1.3mm
Series LXDC3EP
Packaging Tape & Reel (TR)
Operating Temperature -30°C~85°C
Physical
Number of Pins 9
Package / Case 9-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
