PMJ4718TP
RoHS
RoHS compliant
RoHS compliantPackage 13-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
3.3; 0.8-2.5; 30; 75
PDF
/
Inventory: 6556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Through Hole
Package / Case 13-DIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Series PMJ 4000 (75W)
Size / Dimension 1.37Lx1.12W x 0.35 H 34.8mmx28.5mmx9.0mm
Feature Adjustable Output, Remote On/Off, Remote Sense
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 13
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Power (Watts) 75W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form PIN/PEG
Number of Functions 1
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 94.5%
Voltage - Input (Max) 3.65V
Output Voltage 2.5V
Voltage - Output 1 0.8V~2.5V
Voltage - Input (Min) 2.95V
Input Voltage-Nom 3.3V
Trim/Adjustable Output YES
Current - Output (Max) 30A
Control Features Enable, Active Low
Total Power Output-Max 75W
Compliance
RoHS Status ROHS3 Compliant
