PMH8318TP
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
12; 0.8-1.8; 18; 32.4
PDF
/
Buying Options
Total Price: USD $7.96
Unit Price: USD $7.96005
≥1 USD $7.96005
≥10 USD $6.5322
≥100 USD $6.32795
≥500 USD $6.1237
≥1000 USD $5.91945
Inventory: 8601
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Through Hole
Package / Case 10-DIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Series PMH 8000 (99W)
Size / Dimension 1.49Lx0.87W x 0.35 H 38.0mmx22.1mmx9.0mm
JESD-609 Code e3
Feature Adjustable Output, Remote On/Off, Remote Sense
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 10
ECCN Code EAR99
Type Non-Isolated PoL Module
Terminal Finish TIN
Applications ITE (Commercial)
Power (Watts) 32W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 89.5%
Voltage - Input (Max) 13.2V
Voltage - Output 1 0.8V~1.8V
Voltage - Input (Min) 10.8V
Input Voltage-Nom 12V
Trim/Adjustable Output YES
Current - Output (Max) 18A
Control Features Enable, Active Low
Total Power Output-Max 32.4W
Compliance
RoHS Status ROHS3 Compliant
