PKV5222PI
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
18-72; +5,-5; 0.25; 2.5
PDF
/
Buying Options
Total Price: USD $26.53
Unit Price: USD $26.532
≥1 USD $26.532
≥10 USD $26.32784
≥100 USD $26.12368
≥500 USD $25.71536
≥1000 USD $24.49084
≥3000 USD $22.44997
Inventory: 165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 10 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~95°C With Derating
Series PKV (3W)
Size / Dimension 1.25Lx0.80W x 0.42 H 31.8mmx20.3mmx10.7mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN (118) OVER NICKEL (59)
Applications ITE (Commercial)
Power (Watts) 2.5W
Additional Feature -5 V ADDITIONAL OUTPUT AVAILABLE, IT CAN ALSO OPERATE FROM A 60 V NOMINAL INPUT
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 72V
Output Voltage 5V
Voltage - Output 1 5V
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 250mA 250mA
Voltage - Output 2 -5V
Compliance
RoHS Status ROHS3 Compliant
