PKV3321PI
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
9-36; +12,-12; 0.125; 3
PDF
/
Buying Options
Total Price: USD $59.07
Unit Price: USD $59.0653
≥1 USD $59.0653
≥10 USD $48.46425
≥100 USD $46.94995
≥500 USD $45.43565
≥1000 USD $43.9204
Inventory: 13
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 10 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~95°C With Derating
Series PKV (3W)
Size / Dimension 1.25Lx0.80W x 0.42 H 31.8mmx20.3mmx10.7mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN (118) OVER NICKEL (59)
Applications ITE (Commercial)
Power (Watts) 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 125mA 125mA
Voltage - Output 2 -12V
Total Power Output-Max 3W
Compliance
RoHS Status ROHS3 Compliant
