PKR4128BSI
RoHS
RoHS compliant
RoHS compliantPackage 18-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
36-75; 3.3,5.0; 1.5, 1.4; 13
PDF
/
Inventory: 4033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 18-SMD Module
Surface Mount NO
Technical
Operating Temperature -45°C~110°C With Derating
Packaging Tape & Reel (TR)
Series PKR 4000B
Size / Dimension 1.88Lx1.11W x 0.31 H 47.8mmx28.1mmx8.0mm
Feature Adjustable Output, Remote On/Off
Part Status Active
Number of Terminations 18
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 12W
Technology HYBRID
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-N18
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 88.8%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 3.3V
Voltage - Output 1 3.3V
Voltage - Input (Min) 36V
Input Voltage-Nom 53V
Trim/Adjustable Output YES
Current - Output (Max) 1.5A 1.4A
Control Features Enable, Active Low
Voltage - Output 2 5V
Compliance
RoHS Status ROHS3 Compliant
