V48SR1R825NRFA
RoHS
/
Package 8-DIP Module, 1/16 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 1.8V 25A 66W 8-Pin 1/16-Brick
PDF
/
Inventory: 6084
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 22.9mm
Length 33mm
Height 11.4046mm
Diameter 9.398mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Current - Output 1 25A
Control Features Enable, Active Low
Output Power 65W
Output Current 25A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Max Output Current 25A
Output Voltage 1.8V
Voltage - Isolation 2.25kV
Efficiency 87%
Number of Outputs 1
JESD-30 Code R-XDMA-P8
Pin Count 8
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 45W
Power (Watts) 66W
Applications ITE (Commercial)
Color Black
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, OCP, OTP, OVP, UVLO
Size / Dimension 1.30Lx0.90W x 0.37 H 33.0mmx22.8mmx9.5mm
Series Delphi V48SR (66W)
Published 2007
Packaging Tray
Operating Temperature -40°C~121°C
Physical
Material Metal
Package / Case 8-DIP Module, 1/16 Brick
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
