PB01D1205A image
Favorite
PB01D1205A image
Favorite

PB01D1205A

Delta Electronics
RoHS
RoHS RoHS compliant
Package 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Module DC-DC 2-OUT -5V/5V -0.1A/0.1A 1W 5-Pin SIP
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37424
≥1 USD $5.37424
≥10 USD $5.07004
≥100 USD $4.78305
≥500 USD $4.51231
≥1000 USD $4.2569
≥3000 USD $4.01594
Inventory: 8238
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 6.096mm
Length 19.558mm
Height 10.16mm

Technical

Min Input Voltage (DC) 10.8V
Max Input Voltage (DC) 13.2V
Current - Output 2 -100mA
Current - Output 1 100mA
Max Input Voltage 13.2V
Min Input Voltage 10.8V
Voltage - Output 2 -5V
Output Power 1W
Current - Output (Max) 100mA 100mA
Voltage - Input (Min) 10.8V
Voltage - Output 1 5V
Max Output Current 100mA
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 74%
Number of Outputs 2
Max Power Dissipation 1W
Power (Watts) 1W
Applications Medical
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.6mmx6.0mmx10.2mm
Series PB01S/D (1W)
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Package / Case 5-SIP Module
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 9 Weeks
