HA1SV12004PRFA
RoHS
/
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 50W
PDF
/
Inventory: 6453
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mounting Type Through Hole
Package / Case Half Brick
Supplier Device Package Half Brick
Technical
Operating Temperature -40°C~100°C With Derating
Packaging Tray
Series Delphi HA1SV (50W)
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Feature Remote On/Off, OCP, OTP, OVP, UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial), Railway
Power (Watts) 50W
Number of Outputs 1
Efficiency 86%
Voltage - Isolation 3kV
Voltage - Input (Max) 154V
Voltage - Output 1 12V
Voltage - Input (Min) 53V
Current - Output (Max) 4.2A
Control Features Enable, Active High
Compliance
RoHS Status RoHS Compliant
