DD03D2415A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 2-OUT -15V/15V -0.1A/0.1A 2W 12-Pin DIP
PDF
/
Buying Options
Total Price: USD $12.63
Unit Price: USD $12.628
≥1 USD $12.628
≥10 USD $12.5312
≥100 USD $12.43528
≥500 USD $12.24403
≥1000 USD $11.86152
≥3000 USD $10.71356
Inventory: 151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 12 Leads
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2012
Series DD03S/D (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature OCP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Applications ITE (Commercial)
Power (Watts) 3W
Max Power Dissipation 3W
Number of Outputs 2
Efficiency 81%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Max Output Current 100mA
Voltage - Output 1 15V
Voltage - Input (Min) 18V
Current - Output (Max) 100mA 100mA
Output Power 2W
Voltage - Output 2 -15V
Min Input Voltage 18V
Max Input Voltage 36V
Current - Output 1 100mA
Current - Output 2 -100mA
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 18V
Dimensions
Height 10.16mm
Length 31.75mm
Width 20.32mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
