PCN1-S5-D15-M
RoHS
/
Package SMD/SMT
Category Power Supplies - Board Mount / DC DC Converters
Description
PDF
/
Inventory: 4186
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 9.906mm
Length 16.256mm
Height 7.366mm
Technical
Max Input Voltage 5.5V
Min Input Voltage 4.5V
Voltage - Output 2 -15V
Power Dissipation-Max 1W
Analog IC - Other Type DC-DC UNREGULATED POWER SUPPLY MODULE
Voltage - Output 1 15V
Max Output Current 33mA
Voltage - Isolation 1.5kV
Efficiency 78 %
Number of Outputs 2
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Pbfree Code yes
Feature SCP
Physical
Package / Case SMD/SMT
Mount Surface Mount
