VYB15W-Q24-D12
RoHS
/
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER DC/DC 15W +/-12V 625MA
PDF
/
Inventory: 7761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 11.176mm
Technical
Isolation Isolated
Voltage - Output 2 -12V
Control Features Enable, Active High
Output Power 15W
Current - Output (Max) 625mA 625mA
Voltage - Input (Min) 9V
Max Output Current 625mA
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 87%
Number of Outputs 2
Max Power Dissipation 15W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Size / Dimension 2.00Lx1.00W x 0.44 H 50.8mmx25.4mmx11.3mm
Series VYB15W (15W)
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
