VHB75-D12-S12

CUI Inc.
RoHS
RoHS RoHS compliant
Package 9-DIP Module, 1/2 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description CONVERTER DC/DC 12V OUT 75W
PDF
/
Inventory: 5863
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 57.9mm
Height 12.7mm

Technical

Control Features Enable, Active High
Output Power 75W
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Voltage - Output 1 12V
Max Output Current 6.25A
Output Voltage 12V
Voltage - Input (Max) 18V
Voltage - Isolation 1.5kV
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Frequency 400kHz
Terminal Pitch 7.62mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 75W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series VHB75 (75W)
Published 2011
Packaging Bulk
Operating Temperature -40°C~100°C

Physical

Package / Case 9-DIP Module, 1/2 Brick
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
