VFK600-D48-S28

CUI Inc.
RoHS
RoHS RoHS compliant
Package Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description DC/DC CONVERT ISO 1.5KV 28V 25A
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module

Technical

Operating Temperature -40°C~100°C
Packaging Bulk
Published 2016
Series VFK600 (700W)
Size / Dimension 7.84Lx4.99W x 1.54 H 199.1mmx126.8mmx39.1mm
Pbfree Code yes
Part Status Active
Output Power 600W
Current - Output (Max) 25A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 28V
Output Voltage 28V
Voltage - Input (Max) 75V
Efficiency 91%
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 700W
Type Enclosed
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Height 39.116mm
