V7809-500

CUI Inc.
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONVERTER DC/DC REG 9V 500MA
PDF
/
Buying Options
Total Price: USD $5.76
Unit Price: USD $5.7552
≥1 USD $5.7552
≥10 USD $5.67248
≥100 USD $5.59064
Inventory: 42
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mounting Type Through Hole
Package / Case 3-SIP Module
Surface Mount NO

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Published 2012
Series V78-500
Size / Dimension 0.45Lx0.30W x 0.40 H 11.4mmx7.6mmx10.2mm
Feature OTP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
Type Linear Regulator Replacement
Applications ITE (Commercial)
Power (Watts) 4.5W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Number of Outputs 1
Efficiency 95%
Voltage - Input (Max) 32V
Output Voltage 9V
Voltage - Output 1 9V
Voltage - Input (Min) 11V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 500mA
Total Power Output-Max 4.5W

Dimensions

Width 7.5mm

Compliance

RoHS Status RoHS Compliant
