PYBE20-Q48-S24-T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC-DC ISOLATED, 20 W, 18-75 VDC
PDF
/
Buying Options
Total Price: USD $32.83
Unit Price: USD $32.8328
≥1 USD $32.8328
≥10 USD $32.57584
≥100 USD $32.32387
≥500 USD $30.303715
≥1000 USD $27.7783
Inventory: 167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Chassis Mount
Surface Mount YES
Technical
Operating Temperature -40°C~85°C With Derating
Packaging Tray
Series PYBE20 (20W)
Size / Dimension 2.99Lx1.24W x 0.83 H 76.0mmx31.5mmx21.2mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 20W
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Number of Functions 1
JESD-30 Code R-XDMA-X6
Number of Outputs 1
Approval Agency CE, cURus
Efficiency 88%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 24V
Voltage - Output 1 24V
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Current - Output (Max) 834mA
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Control Mode VOLTAGE-MODE
Total Power Output-Max 20W
Compliance
RoHS Status RoHS Compliant
