PYBE20-Q24-S3

CUI Inc.
RoHS
RoHS RoHS compliant
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC-DC ISOLATED, 20 W, 9-36 VDC
PDF
/
Buying Options
Total Price: USD $20.41
Unit Price: USD $20.411035
≥1 USD $20.411035
≥10 USD $19.255694
≥100 USD $18.165749
≥500 USD $17.137503
≥1000 USD $16.167448
Inventory: 8627
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mounting Type Through Hole
Package / Case 6-DIP Module
Surface Mount NO

Technical

Operating Temperature -40°C~85°C With Derating
Series PYBE20 (20W)
Size / Dimension 2.00Lx1.00W x 0.46 H 50.8mmx25.4mmx11.8mm
Feature Remote On/Off, OCP, OVP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 17W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-XDMA-P6
Number of Outputs 1
Approval Agency UL, EN, IEC
Efficiency 86%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 3.3V
Voltage - Output 1 3.3V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Current - Output (Max) 5A
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Control Mode VOLTAGE-MODE

Dimensions

Length 50.8mm
Width 25.4mm

Compliance

RoHS Status RoHS Compliant
