PYBE20-Q24-D12-DIN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC-DC ISOLATED, 20 W, 9-36 VDC
PDF
/
Buying Options
Total Price: USD $35.6
Unit Price: USD $35.596
≥1 USD $35.596
≥10 USD $35.31616
Inventory: 73
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Control Mode VOLTAGE-MODE
Voltage - Output 2 -12V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Current - Output (Max) 834mA 834mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 88%
Approval Agency CE, cURus
Number of Outputs 2
JESD-30 Code R-XDFM-X6
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Power (Watts) 20W
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 2.99Lx1.24W x 0.87 H 76.0mmx31.5mmx22.2mm
Series PYBE20 (20W)
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount YES
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 10 Weeks
