PYB30-Q48-D5-U
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER +/-5V 30W UFRM
PDF
/
Buying Options
Total Price: USD $60.17
Unit Price: USD $60.173571
≥1 USD $60.173571
≥10 USD $56.767511
≥100 USD $53.554263
≥500 USD $50.52289
≥1000 USD $47.6631
Inventory: 1184
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module
Weight 58.000006g
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2016
Series PYB30-U (30W)
Size / Dimension 2.66Lx2.16W x 0.75 H 67.5mmx55.0mmx19.1mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Max Power Dissipation 30W
Number of Outputs 2
Approval Agency EN, IEC
Efficiency 86%
Voltage - Input (Max) 75V
Voltage - Output 1 5V
Voltage - Input (Min) 18V
Current - Output (Max) 3A 3A
Output Power 30W
Voltage - Output 2 -5V
Current - Output 1 3A
Current - Output 2 3A
Dimensions
Height 19.05mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
