PYB20-Q48-D12
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
PYB20 Series 20 W Dual Output ±12 V Encapsulated DC-DC Converter
PDF
/
Inventory: 1131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 50.8mm
Height 11.938mm
Technical
Isolation Isolated
Voltage - Output 2 -12V
Control Features Enable, Active High
Output Power 20W
Current - Output (Max) 834mA 834mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 18V
Max Output Current 834mA
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 88%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-MDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 20W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Size / Dimension 2.00Lx1.00W x 0.47 H 50.8mmx25.4mmx11.8mm
Series PYB20 (20W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 28.349523g
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
