PYB15-Q48-D5-U
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER +/-5V 15W UFRM
PDF
/
Buying Options
Total Price: USD $32.35
Unit Price: USD $32.346254
≥1 USD $32.346254
≥10 USD $30.515337
≥100 USD $28.788055
≥500 USD $27.158545
≥1000 USD $25.621268
Inventory: 1279
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 19.05mm
Technical
Voltage - Output 2 -5V
Output Power 15W
Current - Output (Max) 1.5A 1.5A
Voltage - Input (Min) 18V
Voltage - Output 1 5V
Voltage - Input (Max) 75V
Efficiency 86%
Approval Agency EN, IEC
Number of Outputs 2
Max Power Dissipation 15W
Type Enclosed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 2.16Lx2.06W x 0.75 H 54.9mmx52.3mmx19.1mm
Series PYB15-U (15W)
Published 2016
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 28.349523g
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 13 Weeks
