PYB15-Q48-D12-DIN
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER +/-12V 15W DIN
PDF
/
Buying Options
Total Price: USD $42.29
Unit Price: USD $42.287064
≥1 USD $42.287064
≥10 USD $39.893447
≥100 USD $37.635326
≥500 USD $35.50503
≥1000 USD $33.495313
Inventory: 1266
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Package / Case Module
Weight 69.99999g
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2016
Series PYB15-DIN (15W)
Size / Dimension 2.99Lx1.24W x 0.87 H 76.0mmx31.5mmx22.2mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Max Power Dissipation 15W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Approval Agency EN, IEC
Efficiency 86%
Voltage - Input (Max) 75V
Voltage - Output 1 12V
Voltage - Input (Min) 18V
Current - Output (Max) 625mA 625mA
Output Power 15W
Voltage - Output 2 -12V
Current - Output 1 625mA
Current - Output 2 625mA
Dimensions
Height 22.098mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
