PYB15-Q24-D5-T
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER +/-5V 15W CM
PDF
/
Buying Options
Total Price: USD $36.46
Unit Price: USD $36.456623
≥1 USD $36.456623
≥10 USD $34.393037
≥100 USD $32.446263
≥500 USD $30.609685
≥1000 USD $28.87706
Inventory: 1093
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 21.336mm
Technical
Current - Output 2 1.5A
Current - Output 1 1.5A
Voltage - Output 2 -5V
Output Power 15W
Current - Output (Max) 1.5A 1.5A
Voltage - Input (Min) 9V
Voltage - Output 1 5V
Voltage - Input (Max) 36V
Efficiency 86%
Approval Agency EN, IEC
Number of Outputs 2
Max Power Dissipation 15W
Type Enclosed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 2.99Lx1.24W x 0.84 H 76.0mmx31.5mmx21.2mm
Series PYB15-T (15W)
Published 2016
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 49.999997g
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 13 Weeks
