PYB10-Q48-S24-T
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER 24V 10W CM
PDF
/
Inventory: 9839
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module
Weight 43.999991g
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2016
Series PYB10-T (10W)
Size / Dimension 2.99Lx1.24W x 0.84 H 76.0mmx31.5mmx21.2mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Enclosed
Max Power Dissipation 10W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Number of Functions 1
JESD-30 Code R-MXMA-X6
Number of Outputs 1
Approval Agency EN, IEC
Efficiency 87%
Voltage - Input (Max) 75V
Output Voltage 24V
Voltage - Output 1 24V
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Power 10W
Current - Output 1 416mA
Dimensions
Height 21.336mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
