PYB10-Q48-D5-T
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER +/-5V 10W CM
PDF
/
Buying Options
Total Price: USD $30.17
Unit Price: USD $30.166488
≥1 USD $30.166488
≥10 USD $28.458955
≥100 USD $26.848071
≥500 USD $25.32837
≥1000 USD $23.894682
Inventory: 1101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module
Weight 43.999991g
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2016
Series PYB10-T (10W)
Size / Dimension 2.99Lx1.24W x 0.84 H 76.0mmx31.5mmx21.2mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Enclosed
Max Power Dissipation 10W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Number of Functions 1
JESD-30 Code R-MXMA-X6
Number of Outputs 2
Approval Agency EN, IEC
Efficiency 83%
Voltage - Input (Max) 75V
Output Voltage 5V
Voltage - Output 1 5V
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 1A 1A
Output Power 10W
Voltage - Output 2 -5V
Current - Output 1 1A
Current - Output 2 1A
Dimensions
Height 21.336mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
