PYB10-Q24-S3-T
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER 3.3V 10W CM
PDF
/
Buying Options
Total Price: USD $37.83
Unit Price: USD $37.8312
≥1 USD $37.8312
≥10 USD $37.532
≥100 USD $37.2361
≥500 USD $34.280954
≥1000 USD $31.916773
≥3000 USD $31.443975
Inventory: 1143
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module
Weight 43.999991g
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2016
Series PYB10-T (10W)
Size / Dimension 2.99Lx1.24W x 0.84 H 76.0mmx31.5mmx21.2mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Enclosed
Power (Watts) 10W
Max Power Dissipation 10W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Number of Functions 1
JESD-30 Code R-MXMA-X6
Number of Outputs 1
Approval Agency EN, IEC
Efficiency 79%
Voltage - Input (Max) 36V
Output Voltage 3.3V
Voltage - Output 1 3.3V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Power 8W
Current - Output 1 2.4A
Total Power Output-Max 8W
Dimensions
Height 21.336mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
