PRF20-Q110-D15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER DC/DC +/-15V OUT 20W
PDF
/
Buying Options
Total Price: USD $85.66
Unit Price: USD $85.657845
≥1 USD $85.657845
≥10 USD $80.809294
≥100 USD $76.23518
≥500 USD $71.919979
≥1000 USD $67.849038
Inventory: 928
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Weight 35.000009g
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2016
Series PRF20 (20W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Isolated Module
Applications ITE (Commercial)
Additional Feature ALSO OPERTAES WITH OUTPUT SUPPLY -15 VDC
Max Power Dissipation 20W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-XDMA-P6
Number of Outputs 2
Efficiency 88.5%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 160V
Output Voltage 15V
Max Output Current 667mA
Voltage - Output 1 15V
Voltage - Input (Min) 43V
Input Voltage-Nom 110V
Trim/Adjustable Output NO
Current - Output (Max) 667mA 667mA
Output Power 20W
Control Features Enable, Active High
Voltage - Output 2 -15V
Dimensions
Height 10.16mm
Length 50.8mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
