PDM2-S24-S3-S
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 2W
PDF
/
Buying Options
Total Price: USD $5.04
Unit Price: USD $5.038337
≥1 USD $5.038337
≥10 USD $4.753145
≥100 USD $4.484099
≥500 USD $4.23028
≥1000 USD $3.990832
Inventory: 1096
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 10.16mm
Technical
Voltage - Input (Min) 10.8V
Voltage - Output 1 3.3V
Max Output Current 400mA
Voltage - Input (Max) 13.2V
Voltage - Isolation 1.5kV
Efficiency 84%
Number of Outputs 1
Max Power Dissipation 1W
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.78Lx0.28W x 0.40 H 19.7mmx7.0mmx10.0mm
Series PDM2-S (2W)
Published 2016
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 6-SIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
