PCN2-S5-S12-S
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 2W
PDF
/
Buying Options
Total Price: USD $5.19
Unit Price: USD $5.192
≥1 USD $5.192
≥10 USD $5.1216
≥100 USD $5.04651
≥500 USD $4.89808
≥1000 USD $4.7498
≥3000 USD $4.601309
Inventory: 83
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 7.2mm
Height 10.16mm
Technical
Total Power Output-Max 2W
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 12V
Max Output Current 167mA
Output Voltage 12V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1kV
Efficiency 86%
Number of Outputs 1
JESD-30 Code R-PSMA-T5
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.28W x 0.40 H 19.6mmx7.2mmx10.2mm
Series PCN2-S (2W)
Published 2010
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 6-SIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
