PCN1-S5-D15-S
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 1W
PDF
/
Buying Options
Total Price: USD $4.92
Unit Price: USD $4.9192
≥1 USD $4.9192
≥10 USD $4.84528
≥100 USD $4.774554
≥500 USD $4.6343
≥1000 USD $4.493773
≥3000 USD $4.353325
Inventory: 70
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Through Hole
Package / Case 6-SIP Module, 5 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2011
Series PCN1-S (1W)
Size / Dimension 0.77Lx0.28W x 0.40 H 19.5mmx7.2mmx10.2mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 1W
Number of Outputs 2
Efficiency 78%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 5.5V
Max Output Current 33mA
Voltage - Output 1 15V
Voltage - Input (Min) 4.5V
Current - Output (Max) 33mA 33mA
Voltage - Output 2 -15V
Dimensions
Height 7.366mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
