PCN1-S5-D12-M-TR

CUI Inc.
RoHS
RoHS RoHS compliant
Package 10-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description Module DC-DC 5VIN 2-OUT 12V/-12V 0.042A/-0.042A 1W 6-Pin SMD Module T/R
PDF
/
Buying Options
Total Price: USD $4.4
Unit Price: USD $4.40478
≥1 USD $4.40478
Inventory: 1170
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Voltage - Output 2 -12V
Current - Output (Max) 42mA 42mA
Voltage - Input (Min) 4.5V
Voltage - Output 1 12V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1.5kV
Efficiency 78%
Number of Outputs 2
Power (Watts) 1W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.64Lx0.39W x 0.29 H 16.2mmx9.8mmx7.4mm
Series PCN1-M (1W)
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C

Physical

Package / Case 10-SMD Module, 5 Leads
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
