SUW30512BP
RoHS
RoHS compliant
RoHS compliantPackage 7-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 3.12W 4.5-9Vin +/-12Vout 0.13A SMT
PDF
/
Inventory: 3074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 6.604mm
Technical
Current - Output 2 130mA
Voltage - Output 3 24V
Nominal Input Voltage 5V
Current - Output 1 130mA
Voltage - Output 2 -12V
Output Power 3W
Output Current 130mA
Current - Output (Max) 130mA 130mA
Voltage - Input (Min) 4.5V
Output Voltage 12V
Voltage - Input (Max) 9V
Voltage - Isolation 500V
Efficiency 76%
Number of Outputs 2
Reach Compliance Code unknown
Depth 6.5mm
Power (Watts) 3.1W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.94Lx0.59W x 0.26 H 24.0mmx15.1mmx6.5mm
Series SUW (3W)
Published 2011
Operating Temperature -40°C~85°C With Derating
Physical
Weight 3.000003g
Package / Case 7-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
