EC4BE24  image
Favorite
EC4BE24  image
Favorite
RoHS
RoHS RoHS compliant
Package 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Isolated DC/DC Converters 10W, 2.00x1.00x0.40 36-72Vin, +/-12Vout
PDF
/
Buying Options
Total Price: USD $24.6
Unit Price: USD $24.595869
≥1 USD $24.595869
Inventory: 5728
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mounting Type Through Hole
Package / Case 5-DIP Module

Technical

Operating Temperature -40°C~100°C With Derating
Published 2005
Series EC4BE (10W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 10W
Subcategory Other Analog ICs
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 500V
Voltage - Input (Max) 72V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Current - Output (Max) 415mA 415mA
Output Power 5W
Voltage - Output 2 -12V
Current - Output 1 415mA
Nominal Input Voltage 48V
Current - Output 2 415mA

Compliance

RoHS Status ROHS3 Compliant
